Agristar Powervator

The AgriStar Powervator is a best-in-class tiller designed to revolutionize land preparation for sowing. This versatile machine combines three essential operations - breaking soil clouds, pulverizing, and leveling—into one efficient process, significantly reducing the time required for land preparation. Suitable for both wet and dry conditions, the AgriStar Powervator ensures optimal performance and superior results for farmers.

Features

Upto 15% diesel savings

Superior soil pulverization

Superior depth of cut

Superior porosity

Longer hours of operation

Features

Lightweight with a strong frame structure

Waterproof Ducone sealing

Oil-bath lubricated rotor bearings

Side drive with gears

Half hitch pyramid for improved aesthetics and strength

Low fuel consumption

Induction-hardened components for longer life

All parts individually powder-coated

Utility gear pair – 1 pair, two applications

Features

Lightweight yet optimally balanced with a strong frame structure

Waterproof Ducone sealing

Oil-bath lubricated rotor bearings

Side drive with gears

Half hitch pyramid for improved aesthetics and strength

Low fuel consumption

Induction-hardened components for longer life

All parts individually powder-coated

Utility gear pair – 1 pair, two applications

Features

Optimum weight with a strong frame structure

Designed to perform in both dry and wet land conditions

Suitable for light to medium soil types

Waterproof Ducone sealing

Efficient operation in both wet and dry land

Available in regular and multi-blade combinations

Oil-bath lubricated rotor bearings

Side drive with gears

Half hitch pyramid for improved aesthetics and strength

Fuel-efficient performance

Induction-hardened components for longer life

All parts individually powder-coated

Utility gear pair – 1 pair, two applications

Features

Heavyweight with a strong frame structure

Dust-proof multi-lip sealing

Capable of working in both wet and dry land conditions

Heavy-duty gearbox made with high-grade materials to withstand greater loads and vibrations

Suitable for deep tillage, especially for uprooting deep-rooted crops

Induction-hardened components for longer life

All parts individually powder-coated

Utility gear pair – 1 pair, two applications

Features

Specially designed for inter-cultivation

Low maintenance and low fuel consumption

3-point hitch compatible with CAT-1 tractors

Easy to maneuver in row crops and orchards

Dust-proof seal

Heavy-duty hitch for better stability

Optimum weight to withstand heavy vibrations

Advantages

Gallery

Product Specification

Variant Wet Light Wet Wet & Dry Dry Mini
Description / Model 4.75 Feet (714V)
5 Feet (815V)
6 Feet (917V)
7 Feet (1020V)		 4.75 Feet (714V)
5 Feet (815V)
5.5 Feet (916V)
6 Feet (917V)
7 Feet (1020V)
8 Feet (1122V)		 4 Feet (512DX)
5 Feet (615DX) (815DX)
5.5 Feet (717DX) (917DX)
6 Feet (718DX) (918DX)
7 Feet (820DX) (1020DX)
8 Feet (922DX) (1122DX) 		5 Feet (615DD)
6 Feet (718DD)
7 Feet (820DD) 		800 SS (408MS)
1000 SS (510MS)
1200 SS (612MS)
1200 MS (612MV)
No. of blades 42/48/54/60 42/48/54/54/60/66 30/36/42/42/48/54
NA/48/54/54/60/66		 36/42/48 16/20/24
Blade type L L L L L
PTO rpm 540
Rotor rpm 170 - 260 170 - 260 170 - 260 160 - 230 SS - 214
MS -170 -260
Weight* , kg 307/317/335/358 355/375/390/405/430/455 347/385/410/420/450/480 430/465/500 195/210/240/250
Primary Gear box Single speed Multi speed Multi speed Multi speed Single speed /
Multi speed (1200MS)
Secondary gearbox Gear drive
Sweep diameter , mm
(Rotorshaft with blades)		 465 465 480/465 480 420
Blade tip to mainframe
clearance, mm		 25 25 35/45 40 - 55 50
Rotor shaft seal Mechanical face
seal(Duo Cone)		 Mechanical face
seal(Duo Cone)		 Mechanical face
seal(Duo Cone)		 Multi Lip Multi Lip
Top mast Hood type Hood type Hood type Flat Type Hood type
Description / Model 4.75 Feet (714V) 5 Feet (815V) 6 Feet (917V) 7 Feet (1020V)
Cutting width (mm) 1374 1529 1754 1948
Working depth (inch.) 3 to 5
No. of blades 42 48 54 60
Blade type L/C L/C L/C L/C
Overall Dimensions
Length, mm 1645 1785 2025 2270
Width, mm 840 840 840 840
Height, mm 1100 1100 1100 1100
PTO rpm 540
Rotor rpm 170 to 260
Weight*, kg 307 317 335 358
Tractor power*, hp 35-45 45-55 50-60 50-60
Primary Gear box Multi speed/Single speed
Secondary gearbox Gear drive
Sweep diameter , mm
(Rotorshaft with blades)		 465
Blade tip to mainframe
clearance, mm		 35
Rotor shaft seal Mechanical face seal(Duo Cone)
Top mast Hood type
3 point linkage CAT II
Description / Model 4.75 Feet
(714V)		 5 Feet
(815V)		 5.5 Feet
(916V)		 6 Feet
(917V)		 7 Feet
(1020V)		 8 Feet
(1122V)
Cutting width (mm) 1374 1529 1700 1754 1948 2226
Working depth (inch.) 3 to 5
No. of blades 42 48 54 54 60 66
Blade type L/C L/C L/C L/C L/C L/C
Overall Dimensions
Length, mm 1645 1785 1954 2025 2270 2520
Width, mm 840 840 840 840 840 840
Height, mm 1100 1100 1100 1100 1100 1100
PTO rpm 540
Rotor rpm 170 to 260
Weight*, kg 355 375 390 405 430 455
Tractor power** , hp 35-45 45-55 50-60 50-60 50-60 55-65
Primary Gear box Multi speed/Single speed
Secondary gearbox Gear drive
Sweep diameter , mm
(Rotorshaft with blades)		 465
Blade tip to mainframe clearance, mm 35
Rotor shaft seal Mechanical face seal(Duo Cone)
Top mast Hood type
3 point linkage CAT II
Description
/Model		 4 Feet
(512DX)		 5 Feet
(615DX)		 5.5 Feet
(717DX)		 6 Feet
(718DX)		 7 Feet
(820DX)		 8 Feet
(922DX)		 5 Feet
(815DX)		 5.5 Feet
(917DX)		 6 Feet
(918DX)		 7 Feet
(1020DX)		 8 Feet
(1122DX)
Cutting width (mm) 1190 1495 1662 1740 1985 2230 1529 1700 1754 1948 2226
Working depth (inch.) 4 to 6 3 to 5
No. of blades 30 36 42 42 48 54 48 54 54 60 66
Blade type L/C L/C L/C L/C L/C L/C L/C L/C L/C L/C L/C
Overall Dimensions
Length, mm 1486 1790 1970 2040 2285 2535 1790 1970 2040 2285 2535
Width, mm 840 840 840 840 840 840 840 840 840 840 840
Height, mm 1115 1115 1115 1115 1115 1115 1115 1115 1115 1115 1115
PTO rpm 540
Rotor rpm 170 to 260
Weight* , kg 347 385 410 420 450 480 385 410 420 450 480
Tractor power** , hp 35-45 45-55 50-60 50-60 50-60 55-65 45-55 50-60 50-60 50-60 55-65
Primary Gear box Multi speed/Single speed
Secondary gearbox Gear drive
Sweep diameter, mm
(Rotorshaft with blades)		 480 465
Blade tip to mainframe
clearance, mm		 35 45
Rotor shaft seal Mechanical face seal(Duo Cone)
Top mast Hood type
3 point linkage CAT I & CAT II
Description / Model 5 Feet (615DD) 6 Feet (718DD) 7 Feet (820DD)
Cutting width (mm) 1495 1740 1985
Working depth (inch.) 5 to 6
No. of blades 36 42 48
Blade type L/C L/C L/C
Overall Dimensions
Length, mm 1800 2045 2290
Width, mm 840 840 840
Height, mm 1140 1140 1140
PTO rpm 540
Rotor rpm 160 to 230
Weight* , kg 430 465 500
Tractor power** , hp 40-55 50-65 55-70
Primary Gear box Multi speed
Secondary gearbox Gear drive
Sweep diameter , mm
(Rotorshaft with blades)		 480
Blade tip to mainframe
clearance, mm		 Adjustable - 55 and 40
Rotor shaft seal Mulit lip seal
Top mast Flat type
3 point linkage CAT II
Description / Model 700 SS (407MS) 800 SS (408MS) 1000 SS (510MS) 1200 SS (612MS) 1200 MS (612MV)
Cutting width (mm) 700 800 1000 1200 1200
Working depth (inch.) 3 to 4
No. of blades 16 16 20 24 24
Blade type L L L L L
Overall Dimensions
Length, mm 900 1042 1210 1460 1460
Width, mm 785 785 785 785 785
Height, mm 965 965 965 1075 1075
PTO rpm 540
Rotor rpm 214 170 to 260
Weight* , kg 185 195 210 240 250
Tractor power** , hp 15-20 15-20 15-25 25-30 25-30
Primary Gear box Single speed Multi speed
Secondary gearbox Gear drive
Sweep diameter , mm
(Rotorshaft with blades)		 420
Blade tip to mainframe
clearance, mm		 50
Rotor shaft seal Mulit lip seal
Top mast Hood type
3 point linkage CAT I & CAT I 'N'

* Without Cardan shaft and Oil, * *Indicative
